V01 Semi Automatic Ointment Filling Machine

The machine typically consists of a hopper or tank that holds the ointment or cream, a filling nozzle or nozzles that dispense the product into the containers, and a control system that regulates the flow of the product and the speed of the filling process.

Description

Features:

A semi-automatic ointment filling machine is a piece of equipment that is designed to fill ointment or cream into containers.  It is called “semi-automatic” because some aspects of the filling process require manual intervention, while others are automated.

To use the machine, an operator typically places empty containers onto a conveyor or into a holder, and then activates the filling cycle using a control panel.  The machine then dispenses the desired amount of product into each container, which is then ready for labeling and packaging.

While a semi-automatic ointment filling machine requires some manual intervention, it can significantly increase the speed and accuracy of the filling process compared to filling containers by hand.  It is commonly used in the pharmaceutical, cosmetic, and food industries, among others.



Features of semi-automatic ointment filling machines include:

1.Material of Construction: The machine is made of high-quality stainless steel, which ensures the machine’s durability and resistance to corrosion.

2.Filling Accuracy: Semi-automatic ointment filling machines are designed to achieve high filling accuracy, ensuring that each container is filled with the correct volume of product.

3.Easy to Clean: Semi-automatic ointment filling machines are easy to clean, and the machine’s design allows for easy disassembly and reassembly, making maintenance simple.

4.Cost-Effective: Semi-automatic ointment filling machines are cost-effective compared to fully automatic machines, making them an ideal choice for small to medium-sized businesses.

5.Adjustable Filling Speed: The filling speed of a semi-automatic ointment filling machine can be adjusted to meet the requirements of different products.

6.Safety Features: Semi-automatic ointment filling machines come with various safety features to ensure the safety of the operator and the product.These features include emergency stop buttons, safety guards, and overfill protection.

7.User-Friendly: Semi-automatic ointment filling machines are user-friendly and easy to operate.

8.Versatile: Semi-automatic ointment filling machines can be used to fill a variety of products, including creams, lotions, gels, and ointments.



In conclusion, a semi-automatic ointment filling machine is an essential tool for businesses that require accurate and efficient filling of their products.

PARAMETER:

Model

MIC V01

Voltage

220V/380V 50/60HZ

Power

30W

Air Pressure

0.4-0.6MPa

Filling Speed

5-25 bottles/min

Filling Accuracy

±1%

Dimension(L*W*H)

1000*480*700mm

Filling Range

10-20ML. 25-250ML. 50-500ML.100-1000ML.250-2500ML. 1000-5000ML

Weight

35 Kg

Filling Material

Juice, Oil, Water, Sauce, Toothpaste, Cosmetic Cream, Hand Cream, Honey and etc

Note: If you need special customization. please feel free contact me.
