ZF12 Wax Chili Sauce Filling Machine ( Speed 3000 bottles per hour )

It can fill liquid, such as high viscosity material and foam liquid, oil, sauce, tomato sauce, honey, shampoo, emulsion lubricating oil and so on. It can be widely used in food, chemical, medicine, cosmetics, agricultural and chemical industries.

Description

FEATURES:

Brief Introduction of Our ZF12 Chili Sauce Filling Machine:
It can fill liquid, such as high viscosity material and foam liquid, oil, sauce, tomato sauce, honey, shampoo, emulsion lubricating oil and so on. It can be widely used in food, chemical, medicine, cosmetics, agricultural and chemical industries.

Five Competitive Edges of Our ZF12 Chili Sauce Filling Machine:
1.Its design is very novel, it is easy to convert the size of the format, and the speed is very fast
2.It can be transported with standard or unstable bottles with ice hockey.
3.The docking gas station model is useful, and the diving nozzle is filled from bottom to top.
4.It uses PLC control system, and can fix the discharge port according to the filling bottle, and the operation can be completed by touch screen.
5.This machine uses a servo ball screw to run the piston cylinder. Automatic servo piston filling machine not only has the advantages of ordinary filling machine, but also can expand the range of filling materials. It can effectively fill materials containing particles and long solid content.

The following is a transaction case of our company. This filling and capping packaging production line is filled with mexican chili sauce exported from the United States. It is installed and trained overseas by three engineers of our company. Our engineers went to the customer’s factory for on-site guidance and training in April 2018. The products produced by the customer are very good and are very satisfied with our service.

PARAMETER:

CONFIGURATION:

Filling Nozzle12 Nozzles
Filling Volume200ml-1000ml
Filling FormPiston Type
Speed3000BPH(Base on 350ml)
Accuracy±99%
MaterialRack SUS304 (Material Contact Parts: SUS316)
Air Pressure0.6-0.8 Mpa
Power2.8kw/480 V 60Hz 3P
Conveyor Width152mm
POM Chain Height900+/-25mm
PartsBrand
Touch ScreenTouchWin
PLCSchneider
Solenoid ValveAirTac
Bottle Inspection PhotoelectricAopu Shi Japan
Approach SwitchNetherlands
Differential SwitchNetherlands
Air HandlingAirTac
Button and other low-voltage electricalSchneider
AlarmReal time fault alarm, important
failure can stop automatically
Servo MotorTaiwan TECO
Double Ball Screw RodMic
FunctionFilling Count
MaterialContact parts with 316 stainless steel,
other main parts made of 304 stainless steel
Seal RingCarbon PTFE fiber material, corrosion,
wear resistance, good sealing

APPLY:
