Prefilled Syringe Filling Machine ( Speed 1-5000 syringes per hour )

It is a pre-filling machine which is specifically designed for laboratory pre-filling syringes and suitable for filling 1-20ml glass syringe (BD tube).

Description

FEATURES:

Brief Introduction of Our Prefilled Syringe Filling Machine:
It is a prefilled syringe filling machine which is specifically designed for laboratory pre-filling syringes and suitable for filling 1-20ml glass syringe (BD tube).

Basic Function of Our Prefilled Syringe Filling Machine:
1.The mixer syringe is automatically placed into the thumbwheel by chute and will down the chute as rows. The dial wheel rotates intermittently. One feeding wheel only serve for one syringe and will transport them to the next working part. (It can also be carried out as the way of using the automatic feeding mechanism)
2.The filling process: After the syringe is brought to the filling part, it will be inserted by a single liquid filling needle which will rise and fill at the same time. Besides, the syringe is sealed for vacuum as the filling going on.
3.The stopper: The syringe is passed to the stopper station by dial wheel and is stoppered by the stopper which is sent to the top of the syringe through a special track.
4.The finished products: After the syringe is filled and sealed, it enters the collecting part where it can be manually picked up when it slides out through the suspension.

Four Features of Our Prefilled Syringe Filling Machine:
1.It is driven by servo motor but not the traditional mechanical transmission, so it has not only simple but also reliable operation.
2.It is both adjustable in filling speed and the degree and time of plugging vacuum, which make it suitable for different viscosity of oil and gel filling plug.
3.It is equipped with a smart touch screen to save various specifications of working procedures, so when the specification is changed, it is still able to get the corresponding program screen directly.
4.It is easy to move for its small area occupied, which make it suitable for scenario like laboratory or small batch production.

PARAMETER

CONFIGURATION:

Filling volume1-10ml (can customize)
Production capacity5000 pieces/HOUR (Determined according to the consistency and loading of the gel)
Filling nozzle5 piece ( can customize according to production speed)
Plugging nozzle5 piece ( can customize according to production speed)
Filling accuracy+/-1.5% – +/-2% (filling paste gel)
Power3.5kw
Air compressor0.2-0.6 Mpa
Size2500x1350x1600
Servo motor, driverLG
Displaypro-face
Motion controllerbeofu (Germany)
Circuit breaker, contactorSiemens or schneider
Miniature relaypanasonic
Switching power supplyTaiwan mingwei
Photoelectric detection switchotto nix or easy to measure
Filling pumpceramic pump
Infusion needle, plug track, oscillating bucket, plug rod316L stainless steel
Machine surface304 stainless steel drawing plate
Dial wheelwhite POM
Door opening coverplexiglass
Vacuum pump and vacuum systemthe equipment comes with itself
