Silicone Filling Machine(Speed 10-30 Bottles Per Minute)

The silicone filling machine typically consists of a hopper or reservoir where the silicone material is stored, a metering system that controls the amount of material to be dispensed, and a nozzle or filling head that dispenses the material into the containers.

Description

Features:

The silicone filling machine typically consists of a hopper or reservoir where the silicone material is stored, a metering system that controls the amount of material to be dispensed, and a nozzle or filling head that dispenses the material into the containers.

These machines are commonly used in the manufacturing and packaging of various products, including electronics, automotive parts, construction materials, and household goods, among others.The use of silicone filling machines helps to increase production efficiency and accuracy, reduce material waste, and improve product quality and consistency.


The main difference between a semi-automatic silicone filling machine and an automatic silicone filling machine is the level of automation involved in the filling process.

A semi-automatic silicone filling machine requires manual intervention during the filling process, while an automatic silicone filling machine is fully automated and does not require operator intervention during the filling process.

In a semi-automatic silicone filling machine, the operator manually loads the containers onto the filling machine and initiates the filling process.The filling process is controlled by the machine, but the operator needs to monitor the process to ensure the containers are being filled correctly.After the filling process is complete, the operator removes the filled containers and prepares them for the next stage of processing.

In contrast, an automatic silicone filling machine requires no operator intervention during the filling process.The machine automatically loads the containers onto the filling machine, initiates the filling process, and monitors the filling process to ensure the containers are being filled correctly.After the filling process is complete, the machine automatically removes the filled containers and prepares them for the next stage of processing.

The choice between a semi-automatic and automatic silicone filling machine depends on factors such as production volume, required throughput, and level of automation desired.Automatic filling machines are generally more expensive but can offer higher production rates and more consistent filling accuracy.Semi-automatic filling machines are typically more affordable and offer more flexibility in terms of production runs and product variability.


Silicone filling machines are chosen for several reasons, including:

1.Product Consistency: Silicone filling machines are designed to dispense consistent amounts of material into each container, ensuring product consistency and quality.

2.Efficiency: Silicone filling machines are capable of high-speed filling and can handle large volumes of material, resulting in increased production efficiency.

3.Accuracy: Silicone filling machines are designed to dispense precise amounts of material, reducing material waste and ensuring accurate filling of each container.

4.Versatility: Silicone filling machines can handle a wide range of silicone materials, including sealants, adhesives, gels, and pastes, and can fill containers of different shapes and sizes.

5.Cost-effectiveness: Using a silicone filling machine can reduce labor costs and material waste, resulting in cost savings over time.

6.Regulatory Compliance: The use of a silicone filling machine can help ensure compliance with regulatory standards for product filling accuracy and consistency.

Overall, choosing a silicone filling machine can offer several benefits to manufacturers, including increased efficiency, accuracy, consistency, and cost savings, as well as improved regulatory compliance.

PARAMETER:

Add Your Heading Text Here

Filling range



100-300ml

Capacity



10-30 bottles /minute

Voltage



220V/380V

Filling precision



≤±1%

Capping Rate



≥99%

Air Supply



1.3 m3/h 0.4-0.8Mpa

Dimension



1200*1000*1800mm

Weight



550kg

Main motor

Wu XI Qi Peng

PLC Panasonic

JAPAN

Stepping motor

East Japan

Stepping drive

East Japan

Sensor

Germany Sick

Approach switch

BFNFC

Intermediate relay

Schneider

Electromagnetic valve

Si Mai Ge

Encoder

Omron

Mixing motor (optional)

XiangGang Ease

Air cylinder

Si Mai Ge

Bearing

Nsk

Button

Schneider

Air switch

CHNT

Power switch

Omron

Temperature control

HuoYU
