Silicone Cartridge Filling Machine(Speed 10-30 Bottles Per Minute)

A silicone filling machine is designed to accurately measure and dispense silicone material into containers, such as bottles, tubes, or cartridges. The primary function of the machine is to fill these containers with the correct amount of silicone material, ensuring that each container is filled accurately and consistently.

Description

Features:

A silicone filling machine is designed to accurately measure and dispense silicone material into containers, such as bottles, tubes, or cartridges.  The primary function of the machine is to fill these containers with the correct amount of silicone material, ensuring that each container is filled accurately and consistently.

Silicone filling machines are commonly used in industrial settings, such as manufacturing plants, where large quantities of silicone products need to be produced quickly and efficiently.  They can be used to fill a variety of silicone-based products, including sealants, adhesives, coatings, and other viscous materials.

The benefits of using a silicone filling machine include increased efficiency, improved accuracy, and reduced waste.  By automating the filling process, the machine can fill containers at a faster rate than manual methods, while also ensuring that the correct amount of material is dispensed into each container.  This can help to reduce material waste and improve product quality and consistency.



A silicone filling machine is used in a variety of applications where silicone materials need to be accurately dispensed into containers. Some common applications of silicone filling machines include:

1. Manufacturing of sealants: Silicone filling machines are used to fill containers with silicone sealants, which are used in a variety of applications such as construction, automotive, and electronics.

2. Production of adhesives: Filling machines can be used to fill containers with silicone-based adhesives, which are used in many industries including automotive, aerospace, and electronics.

3. Coatings: Silicone filling machines can be used to fill containers with silicone-based coatings, such as protective coatings for electronic components or coatings for architectural glass.

4. Personal care products: Filling machines can be used to fill containers with silicone-based personal care products, such as lotions, creams, and gels.

5. Food and beverage packaging: Silicone filling machines can be used to fill containers with food and beverage products, such as sauces, condiments, and beverages.



Overall, the main purpose of a silicone filling machine is to streamline the process of filling containers with silicone material, improving efficiency and reducing the risk of human error.



PARAMETER:

CONFIGURATION:

Filling Range100-300ML
Capacity10-30 Bottles per minute
Voltage220V/380V
Filling Precision≤±1%
Capping Rate≥99%
Air Supply1.3m³/h 0.4-0.8Mpa
Dimension

1200*1000*1800mm
Weight

550KG
Main Motor
Wu Xi Qi Peng
PLC PanasonicJapan
Stepping MotorEast Japan
Stepping DriveEast Janpan
SensorGermany Sick
Approach SwitchBFNFC
Intermediate RelaySchneider
Electromagnetic ValveSi Mai Ge
EncoderOmron
Mixing Motor(optional)XiangGang Ease
Air CylinderSi Mai Ge
BearingNSK
ButtonSchneider
Air SwitchCHNT
Power SwitchOmron
Temperature ControlJuo Yu
