R60 Automatic Tube Filling Machine(Capacity 60-85 tubes per minute)

This is our full-automatic filling and sealing machine for soft plastic (PE, PP, PVC) pipes. It is applicable to paste, adhesive, AB glue, epoxy glue, skin care cream, hair dye, shoe polish, toothpaste, etc. it can be used for soft plastic pipes and laminated pipes.

Description

Brief Introduction of Our Semi-automatic Hard Tube Silicone Filling Machine:

This is our full-automatic filling and sealing machine for soft plastic (PE, PP, PVC) pipes. It is applicable to paste, adhesive, AB glue, epoxy glue, skin care cream, hair dye, shoe polish, toothpaste, etc. it can be used for soft plastic pipes and laminated pipes.

Two Competitive Edges of Our Semi-automatic Hard Tube Silicone Filling Machine:

1.It uses cam to control vertical upward filling, and uses rotary valve to fill the bottom, which can be customized according to different requirements.

2.It uses the imported laser Swiss heating gun to heat the tail of the sealing tube, so that the production mode is better than others.

The Working process of Our Semi-automatic Hard Tube Silicone Filling Machine:

1.It can automatically upload test tubes.

2.It can fix the product position.

3.It can automatically fill and heat, seal and cut and produce complete products.

Pay attention to:

1.Engineers can go abroad to install and adjust machines and provide on-site installation guidance services.

2.We have free lifetime warranty consultation and can provide free accessories within one or two years.

3.If you have any questions about our products, we are online 24 hours to provide video explanation and after-sales service.

Control Panel
Sensor
Swiss Hot Gun Sealing System
Cutting Tail

PARAMETER:

CONFIGURATION:

Voltage110V/220V/380V
Power1.1kw
Filling HeadDiving piston filling
Air Pressure0.6-0.8Mpa
Production Capacity60-85 tubes/min
Filling Volume1-300ml
Filling Error± 0.5g
MaterialSS304/316
Dimensions1950*800*1850mm
Weight850KG
PartsBrand
T ouch ScreenSiemens
Main MotorTai Wan chen Bang
PLCSiemens
Stepping MotorEast Japan
Stepping DriveEast Japan
SensorGermany Sick
Approach SwitchGermany Sick
Intermediate RelaySchneider
E lectromagnetic ValveGermany SMC
EncoderOmron
Mixing Motor (Optional)JSCC
Air CylinderSMC
BearingFAGINA
ButtonSchneider
Air SwitchSchneider
Power S witchSchneider
Temperature ControlSchneider

APPLY:

Our service

-We offer our technician for oversea to install and adjust machine, do field installation guidance.

-We provide the full-lifetime warranty consult with one more two years free accessories support.

-24 hours online support, when you meet the problem we will provide video explain
