Description
Brief Introduction of Our Semi-automatic hard tube silicone filling machine:
The machine not only can tightly seal the material, but also can be used for quantitative filling materials of plastic pipes for packaging containers. Automatic filling and sealing machine has a large number of uses, which can be used to package products in pharmaceutical, daily chemical, food, chemical and other industries. In addition, it can not only fill and seal ointment, skin ointment, hair dye, toothpaste adhesive, AB glue and other paste materials, but also fill shoe polish, neoprene, epoxy resin and other liquid materials.
Five Competitive Edges of Our Semi-automatic hard tube silicone filling machine:
1.The material of the machine is 304 stainless steel
2.In order to simplify the process of customer observation, operation and maintenance of the machine, we set up the filling and sealing part above the platform
3.The floor area and volume of the machine are very small. Its usage is very simple. It can adjust the filling volume and speed.
4.When there is a problem with the machine, it will prompt that there is a multi-functional fault, such as no filling, no cover and so on
5.The machine has high efficiency, stable performance and accurate results
PARAMETER：
CONFIGURATION：
| Filling range | 100-300ml |
| Capacity | 10-30 bottles /minute |
| Voltage | 220V/380V |
| Filling precision | ≤±1% |
| Capping Rate | ≥99% |
| Air Supply | 1.3 m3/h 0.4-0.8Mpa |
| Dimension | 1200*1000*1800mm |
| Weight | Weight 550kg |
| Main motor | Wu XI Qi Peng |
| PLC Panasonic | JAPAN |
| Stepping motor | East Japan |
| Stepping drive | East Japan |
| Sensor | Germany Sick |
| Approach switch | BFNFC |
| Intermediate relay | Schneider |
| electromagnetic valve | Si Mai Ge |
| Encoder | Omron |
| Mixing motor (optional) | XiangGang Ease |
| Air cylinder | Si Mai Ge |
| Bearing | Nsk |
| Button | Schneider |
| Air switch | CHNT |
| Power switch | Omron |
| Temperature control | HuoYU |
APPLY:
