Plastic Syringe Filling Machine With Dust Cover ( Speed 20-30 syringes per minute )

It can fill and package all kinds of syringes, boosters and injection tubes in medicine, chemistry, biology and other fields.

Description

Features

Brief Introduction of Our Plastic Syring Filling Machine With Dust Cover:

It can fill and package all kinds of syringes, boosters and injection tubes in medicine, chemistry, biology and other fields.

Nine Competitive Edges of Our Plastic Syring Filling Machine With Dust Cover:
1.Pre filling syringe filling machine can fill accurately and solve bubbles in case of blockage.
2.The operation is automatic and the whole process is monitored.
3.In addition to ordinary liquids, it is also suitable for filling transparent viscous liquids such as ester acid.
4.The pre filling syringe filling machine includes 2 sets of servo motors, which are used for accurate filling, reliable blocking and accurate line by line movement in the filling process.
5.Pre filling syringe filling machine s / s rotary pump. The filling volume setting and precision adjustment can be operated by touch screen without any tools.
6.The pre filling syringe filling machine uses Siemens color touch screen. It can monitor and display the operation status, nitrogen pressure, vacuum pressure and C / a pressure in real time. And there are fault alarm, fault indication and record with position indication. There are many different language displays.
7.The blocking quality of pre filling syringe filling machine is observed and controlled by MVs machine vision system to ensure higher acceptability, which is optional
8.The parameters of the pre filling syringe filling machine can be printed, saved and searched in time.
9.The surface of the machine is coated with SUS 304 and 6061 alumina alloy, and all parts are made of SUS 316L and medical silicone rubber.

PARAMETER:

CONFIGURATION:

Voltage110V/220V/380V
Air Supply0.6-0.8Mpa
Filling Speed20-30pcs/minute
Filling Nozzle1
Motor Power2KW
Air Consumption0.4m³/minute
Filling Accuracy±1%
Plugging Nozzle1

Parts

Brand
Touch ScreenSiemens
Main MotorWuxi Qipeng
Proximity SwitchPefun
Air CylinderTaiwan AirTAC
EncoderJapan Koyo
Air SwitchSchneider
BearingGermany FAG
PLCSiemens
ButtonSchneider
Optoelectronic SwitchGermany Sick
Solenoid ValveTaiwan AirTAC
Power SwitchOmron
Intermediate RelaySchneider
RackSUS304

APPLY:
