Description
FEATURES:
Brief Introduction of Our ZF8 Bottle Filling Capping Machine:
It can be used in food, chemical industry, medicine, cosmetics, pesticides and other industries to fill liquid and cream products, especially for high viscosity materials, butter, palm oil, mayonnaise, honey and ketchup. It can fill liquids, especially high viscosity materials and foam liquids, such as oil, sauce, ketchup, honey, shampoo, lotion, lubricating oil, etc., and can be used on barrels, cans and bottles of different specifications.
The Functions of Our ZF8 Bottle Filling Capping Machine:
1.The design is very flexible. It can quickly convert the size of the format, which is convenient and easy to operate. It can be equipped with a standard conveyor belt or a disc for unstable bottles.
2.The submersible nozzle is filled from bottom to top.
3.Provide docking station model.
Six Competitive Edges of Our ZF8 Bottle Filling Capping Machine:
1.It uses PLC system to control the machine and it has touch screen.
2.Bottle feeding, filling and bottling automatically.
3.The machine is driven by servo motor and driven by twin-screw to control the movement of piston rod, which can fill stably.
4.Double ball screw for filling nozzle.
5.It can operate stably and reliably, be efficient and adapt quickly.
6.It integrates light, machinery, electricity and gas. It can form a production line with capping machine and labeling machine. It is very simple and easy to operate.
PARAMETER:
CONFIGURATION:
Filling head | 8 heads |
Filling volume range | 50-1000ml(Use 1000ml piston cylinder) |
Production speed | ≤1800 Bph basis on 1000ml bottle |
Voltage | 220v/380v |
Power | 3kw |
Suitable bottle’s diameter | Ф40mm-Ф100mm |
Filling error | ≤±1 |
Work pressure | 0.55Mpa-0.65Mpa |
Size | 2000mm × 1400mm× 2500mm |
Weight | 1000kg |
Touch screen | Canada xinjie color |
PLC | Schneider |
Solenoid valve | Taiwan Airtac |
Optoelectronic system | OPTEX |
Micro differential pressure switch | Netherlands |
Servo motor | Taiwan TECO |
Air source treatment | Taiwan Airtac |
Button and low voltage electric appliance | Schneider |
Ball screw | Taiwan |
Reducer | Taiwan VGM |
Switching power supply | Taiwan meanwell |
Material | Contact with the material parts of the 316 materials, and the rest of the 304 stainless steel |
