Automatic Liquid Soap Filling Machine(Such As Pesticides,Disinfectants,Medical Alcohol,Etc.)

A liquid soap filling machine is a type of packaging equipment used to fill liquid soap products into containers of different shapes and sizes. The machine typically consists of a conveyor system, filling nozzles, a control panel, and a pump or gravity feed system to transfer the liquid soap product from a storage tank to the filling nozzles.

Description

FEATURES:

The working principle of a liquid soap filling machine involves the use of a pump or piston mechanism to draw the liquid soap from a supply tank and dispense it into the containers.The machine can be adjusted to control the amount of soap dispensed, ensuring consistent fill volumes for each container.

The main difference between automatic machine and a semi-automatic liquid soap filling machine is the level of automation in the filling process.

An automatic liquid soap filling machine is fully automated and can perform the entire filling process without any human intervention.  It typically includes a conveyor belt, a filling nozzle or nozzles, and a control system.  The containers are placed on the conveyor belt, and the machine fills each container with the desired amount of liquid automatically.  The automatic filling machine can handle a large volume of containers and can fill them quickly and accurately.


Liquid soap filling machines are used in a variety of industries for filling containers with liquid soap and other similar liquid products include:

Cosmetics industry: Liquid soap filling machines are widely used in the cosmetics industry for filling containers with various types of liquid products, such as hand soaps, body washes, shampoos, conditioners, and lotions.

Pharmaceutical industry: Liquid soap filling machines are used in the pharmaceutical industry for filling containers with various types of liquid products, such as cough syrups, liquid medications, and eye drops.

Food and beverage industry: Liquid soap filling machines are used in the food and beverage industry for filling containers with various types of liquid products, such as sauces, dressings, oils, and juices.

Chemical industry: Liquid soap filling machines are used in the chemical industry for filling containers with various types of liquid products, such as cleaning solutions, solvents, and industrial chemicals.

Household and personal care industry: Liquid soap filling machines are used in the household and personal care industry for filling containers with various types of liquid products, such as detergents, fabric softeners, and disinfectants.

In general, liquid soap filling machines are used in any industry that requires accurate, efficient, and consistent filling of liquid products into containers.  They can handle a wide range of container sizes and shapes, as well as different types of liquids, making them a versatile and essential piece of equipment for many industries.

Filling Head
Material Tanl And Valves
Time Control Filling Valve

PARAMETER:

CONFIGURATION:

Filling Heads

12 heads

Min Filling Volume

500ml-5000ml

Production Speed

2000 Bph(basis on 5L bottle)

3000-5000Bph (basis on 1L)

Voltage

220V/380V

Power



1 kw

Application Bottle Type



1-5L different shape bottles

Filling Error



≤±0.5%

Work Pressure



0.55Mpa-0.65Mpa

Size



2000mm × 1000mm× 2200mm

Weight



700 kg

Name

Brand

Touch Screen

Canada Xinjie

PLC

Schneider France

Frequency Conversion

Schneider France

Pneumatic Valve

UAA USA

The Electromagnetic Valve

AirTac Taiwan

Air Cylinder

AirTac Taiwan

Air Source

AirTac Taiwan

Photovoltaic Systems

OPTEX Japan

Differential Pressure Switch

Johnson USA

Switching Power Supply

Mean Well Taiwan

Machine Frame Material

Use PVC Polypropylene material make, the material of our machine’s tank is Acid and

alkali corrosion resistant material can resistant Acid and alkali and corrosion.

APPLY:
