Self-flow Disinfectant Filling Machine(Speed≤2000BPH)

It is a full-automatic direct pressure vacuum filling machine, which integrates light, electricity and gas. It is used to pack disinfectant, pesticide, chemical, water and liquid bottles. Containers of different shapes can be used. It can be matched with capping machine and labeling machine to form a complete production line.

Description

FEATURES:

Brief Introduction of Our Self-flow Disinfectant Filling Machine:

It is a full-automatic direct pressure vacuum filling machine, which integrates light, electricity and gas. It is used to pack disinfectant, pesticide, chemical, water and liquid bottles. Containers of different shapes can be used. It can be matched with capping machine and labeling machine to form a complete production line.



Three Competitive Edges of Our Self-flow Disinfectant Filling Machine:

1.It can control the filling time and fill different quantities of articles. The filling time is 1% second.

2.The working process is controlled by PLC program and carried out on the touch screen. Easy to operate.

3.It can operate stably, produce efficiently and adapt easily. It can change the measurement to the filling specification in a short time. It uses advanced technology, high precision and imported brand filling valve, which will not leak during filling.


The machine is used in various applications such as:

1.Filling of injectable drugs: The vial filling machine is extensively used for filling injectable drugs, which are administered through intravenous, intramuscular, or subcutaneous routes.     Injectable drugs include antibiotics, anti-cancer drugs, vaccines, insulin, and many more.

2.Filling of parenteral nutrition: Parenteral nutrition is a method of delivering nutrients directly into the bloodstream through intravenous infusion.     The vial filling machine is used for filling parenteral nutrition solutions, which are essential for patients who cannot consume food through the digestive system.

3.Filling of diagnostic reagents: Diagnostic reagents are used for medical diagnosis and testing.     The vial filling machine is used for filling diagnostic reagents such as serums, antigens, and antibodies into vials.

4.Filling of biologics: Biologics are a type of pharmaceutical product made from living organisms or their products.     The vial filling machine is used for filling biologics such as monoclonal antibodies, vaccines, and recombinant proteins.

5.Filling of veterinary drugs: The vial filling machine is also used in the veterinary industry for filling and packaging of veterinary drugs such as antibiotics, vaccines, and hormones.

PARAMETER:

CONFIGURATION:

Filling head12heads
Speed≤2000BPH (base on 1000ml water)
Filling volume500-1000ml
Suitable bottle diameterФ40-Ф100mm
Voltage220V/380V
Power1kw
Measure error≤±1‰
Working Pressure0.55Mpa-0.65Mpa
Dimension2000mm × 900mm× 2500mm
Weight500 kg
NameBrand
Touch screenCanada xinjie color
PLCSchneider
Optoelectronic systemOPTEX
Micro differential pressure switchJohnson Controls
Solenoid valveTaiwan Airtac
Bottle feeding and out air cylinderTaiwan Airtac
Air source treatmentTaiwan Airtac
Frequency converterSchneider
Switching power supplyTaiwan meanwell
MaterialContact with the material parts of the 316 materials, and the rest of the 304 stainless steel.

APPLY:
