Description
FEATURES:
The lubricant oil filling machine is used for filling lubricant oils into containers with precision and accuracy.It works by automating the filling process, which helps to improve efficiency, reduce wastage, and ensure consistent filling of the lubricant oil.
The lubricant oil filling machine works by automating the process of filling lubricant oils into containers.
Here’s how it typically works:
1.The operator places the empty containers on the conveyor belt or feeding system of the machine.
2.The machine transports the containers to the filling station.
3.The machine dispenses the lubricant oil from a storage tank using a pump.
4.The oil is transferred through the filling nozzle and into the container.
5.The machine can be programmed to fill a specific volume of oil into each container, which helps to ensure consistent filling and minimize wastage.
6.The machine can also be set to stop automatically when the desired fill level is reached.
Once the filling process is complete, the containers are transported to the next station, such as capping, labeling, or packaging.
The lubricant oil filling machine can be customized to suit different types of lubricant oils and containers, and it can be equipped with various features to improve efficiency and accuracy, such as a level sensor, a weight sensor, and a control panel. The machine can also be integrated with other equipment in the production line to form a fully automated system.
The lubricant oil filling machine has a wide range of applications in various industries, including:
Automotive Industry: Lubricant oil is used in the automotive industry to keep engines and other components running smoothly. The lubricant oil filling machine is used to fill engine oil, transmission fluid, brake fluid, and other lubricant oils into bottles, cans, and other packaging materials.
Manufacturing Industry: Lubricant oil is used in the manufacturing industry to reduce friction, wear, and tear on machinery and equipment. The lubricant oil filling machine is used to fill lubricant oils into drums and other large containers used in manufacturing.
Packaging Industry: The lubricant oil filling machine is used in the packaging industry to fill lubricant oils into bottles, cans, and other packaging materials. The machine can be customized to fill different sizes and shapes of containers.
Chemical Industry: The lubricant oil filling machine is used in the chemical industry to fill various types of lubricant oils, including industrial lubricants, hydraulic oils, gear oils, and compressor oils.
Food and Beverage Industry: The lubricant oil filling machine can also be used in the food and beverage industry to fill cooking oil, vegetable oil, and other food-grade lubricant oils into bottles and other packaging materials.
In summary, the lubricant oil filling machine is used in various industries where the accurate and consistent filling of lubricant oils is important for maintaining product quality and meeting regulatory requirements.
PARAMETER:
CONFIGURATION:
Filling head | 8 heads |
Filling volume range | 50-1000ml(Use 1000ml piston cylinder) |
Production speed | ≤1800 Bph basis on 1000ml bottle |
Voltage | 220v/380v |
Power | 3kw |
Suitable bottle’s diameter | Ф40mm-Ф100mm |
Filling error | ≤±1 |
Work pressure | 0.55Mpa-0.65Mpa |
Size | 2000mm × 1400mm× 2500mm |
Weight | 1000kg |
Touch screen | Canada xinjie color |
PLC | Schneider |
Solenoid valve | Taiwan Airtac |
Optoelectronic system | OPTEX |
Micro differential pressure switch | Netherlands |
Servo motor | Taiwan TECO |
Air source treatment | Taiwan Airtac |
Button and low voltage electric appliance | Schneider |
Ball screw | Taiwan |
Reducer | Taiwan VGM |
Switching power supply | Taiwan meanwell |
Material | Contact with the material parts of the 316 materials, and the rest of the 304 stainless steel |
