ZF12 Sauce Filling Machine(Speed 3000BPH)(Base on 350ml)

ZF12 Sauce filling machine is suitable for filling liquid, such as high viscosity material and foam liquid, general filling oil, sauce, tomato sauce, syrup, detergent, honey, shampoo, lotion, lubricating oil, etc. It is widely used in food, chemical, medicine, cosmetics, agrochemical and other industries.

Description

FEATURES:

Brief Introduction of Our ZF12 Sauce Filling Machine:

ZF12 Sauce filling machine is suitable for filling liquid, such as high viscosity material and foam liquid, general filling oil, sauce, tomato sauce, syrup, detergent, honey, shampoo, lotion, lubricating oil, etc. It is widely used in food, chemical, medicine, cosmetics, agrochemical and other industries.

Seven Competitive Edges of Our ZF12 Sauce Filling Machine:

1.Serve ball-screw system to drive the piston cylinder.

2.This machine adopts touch screen, PLC control machine, all operations can be completed on the touch screen, more simple and clear.

3.Can be filled with particles, long solid material, the machine can be customized according to the material

4.Can be delivered in standard or unstable bottles

5.Our machine uses a more flexible and simple design And Very fast and easy changeover of format size.

6.Docking filling station model available

7.Machine filling head adopts bottom-up filling.

Our factory also offer installation services if you need them.After the machine arrives at your factory, you need to order installation service from our company. During the installation process, we will alsoteach you how to operate and maintain the equipment.

If you are interested in this machine,please contact us.

PARAMETER:

CONFIGURATION:

Filling Nozzle12 Nozzles
Filling Volume200ml-1000ml
Filling FormPiston Type
Speed3000BPH(Base on 350ml)
Accuracy±99%
MaterialRack SUS304 (Material Contact Parts: SUS316)
Air Pressure0.6-0.8 Mpa
Power2.8kw/480 V 60Hz 3P
Conveyor Width152mm
POM Chain Height900+/-25mm
PartsBrand
Touch ScreenTouchWin
PLCSchneider
Solenoid ValveAirTac
Bottle Inspection PhotoelectricAopu Shi Japan
Approach SwitchNetherlands
Differential SwitchNetherlands
Air HandlingAirTac
Button and other low-voltage electricalSchneider
AlarmReal time fault alarm, important
failure can stop automatically
Servo MotorTaiwan TECO
Double Ball Screw RodMic
FunctionFilling Count
MaterialContact parts with 316 stainless steel,
other main parts made of 304 stainless steel
Seal RingCarbon PTFE fiber material, corrosion,
wear resistance, good sealing
