L45 Glue Tube Filling Machine(Toothpaste,AB Glue,30-75 Tubes Per Minute)

It can used for both metal and aluminum tube filling and sealing. Its application range from chemical, pharmaceutical, cosmetics, adhesive and other industries. The specific material filled inside can be food paste, ointment, creams, pigments, adhesives, AB glue, epoxy glue, hair dye, shoe polish, toothpaste, silicone etc.

Description

Features:

Brief Introduction of Our L45-I Automatic Aluminum Tube Filling & Sealing Machine:
It can used for both metal and aluminum tube filling and sealing. Its application range from chemical, pharmaceutical, cosmetics, adhesive and other industries. The specific material filled inside can be food paste, ointment, creams, pigments, adhesives, AB glue, epoxy glue, hair dye, shoe polish, toothpaste, silicone etc.

The Working Process of Our L45-I Automatic Aluminum Tube Filling & Sealing Machine:
1.Automatically putting the tubes into the molds

2.Filling the tube as the fore-setting data

3.Sealing the tube 4 times

4.Unloading the finished product

Four Competitive Edges of Our L45-I Automatic Aluminum Tube Filling & Sealing Machine:
1.The PLC control system with touch screen or control panel adopted in the machine ensure the simple operation and easy using, which also means saving the learning time and high accuracy for computer controlling.

2.The tube mold can be designed as your personal demands. It is convenient to customize the mould based on the specific diameter of the tubes, which make one machine suitable for different producing scenarios.

3.High-accuracy filling with firm and appreciable sealing, the machine is anti-drip as well.

4.Made of high-quality 314 or 316 stainless steels, the machine has steady performance with features of noise-free and pollution-free. What’s more, we adopt a quick-change device in the part which need to be washed, so it will be easy for cleaning process.

Something for Your Attention Before Making Your Order:
You can personalize your machine for choosing the best one for your business,even with different folding ways. But it would be kind of you to provide the specific data about your filling volume, tube material, diameters of your tube, type of filling material and the production speed you need before we offer the suitable quotation for you.

We will recommend the right tube filling sealing machine based on your tube material.

PARAMETER:

CONFIGURATION:

Weight850Kg
Dimension1950*800*1850mm
Power220V/50Hz
Motor2.2Kw
Filling Quantity3-30ml/30-75ml/75-150ml
Capacity30-75 tubes/min
Suitable Filling MaterialAluminum tube
Maximum Tube Dia.80mm
Date Printed1-2 rows(numbers & letters)
Additional FunctionAir Blow after filling
NameBrand
FrameworkSUS 304 Stainless Steel
ButtonSchneider
Main MotorQIPENG, China
PLCPanasonic
Stepping MotorJapan EAST
Stepping DriveJapan EAST
Color Mark SensorPanasonic
Approch SwitchOmron
Media RelayOmron
Magnetic VavleTaiwan AIRTAC
DividerChina, Shangdong
Heating TubeChina
Pneumatic ElementsTaiwan AIRTAC
Pump for FillingOwn Produce (MIC)
Hopper (35L*2 )SUS304

APPLY:
