Automatic Hand Sanitizer Filling Machine ( Speed 3000 bottles per hour )

The machine is widely used in industries from food, chemical, medical to cosmetics and agrochemical. The contents can be ranged from filling liquid to high viscosity materials and foamy liquid, including hand soap, disinfectant, oil, sauce, ketchup, honey, lotion, shampoo, lubricating fluid etc.

Description

FEATURES:

Introduction:
The machine is widely used in industries from food, chemical, medical to cosmetics and agrochemical. The contents can be ranged from filling liquid to high viscosity materials and foamy liquid, including hand soap, disinfectant, oil, sauce, ketchup, honey, lotion, shampoo, lubricating fluid etc.

Four features of our filling capping machine :
1.It is available with both conveyor in standard and unstable bottles.
2.Its flexible design equips itself with fast and easy way to change the format size.
3.It has corresponding filling station type.
4.It adopts the bottom-up filling method with diving nozzle.

The machine employs ball-screw system to drive the piston cylinder. Therefore, in addition to the advantages of traditional automatic servo piston filling machine, it has wider range of materials suitable, such as material which contains particles or has solid long strips. And it can still bring out effective filling performance.

The production line was installed and personnel were trained by 3 professional engineers oversea. We can offer engineers to your factory to give installation service and fix or change the machine later after the sale is deal. Clients are satisfied with our performance and service through the time.

PARAMETER:

CONFIGURATION:

Filling N ozzle12 Nozzles
Filling Volume200ml-1000ml
Filling FormPiston Type
Speed3000BPH(Base on 350ml)
Accuracy±99%
MaterialRack SUS304 (Material Contact Parts: SUS316)
Air Pressure0.6-0.8 Mpa
Power2.8kw/480 V 60Hz 3P
Conveyor Width152mm
POM Chain Height900+/-25mm
PartsBrand
Touch ScreenTouchWin
PLCSchneider
Solenoid ValveAirTac
Bottle Inspection PhotoelectricAopu Shi Japan
Approach SwitchNetherlands
Differential SwitchNetherlands
Air HandlingAirTac
Button and other low-voltage electricalSchneider
Alarm

Real time fault alarm, important failure can stop automatically

Servo MotorTaiwan TECO
Double Ball Screw RodMic
FunctionFilling Count
Material

Contact parts with 316 stainless steel,

other main parts made of 304 stainless steel

Seal Ring

Carbon PTFE fiber material, corrosion,

wear resistance, good sealing

APPLY:
