V01 Toothpaste Tube Filling Machine

It is a kind of equipment for automatic weighing and packing of liquid materials in chemical, food, pesticide and other industries. The high precision electronic weight detection method is adopted for weighing and measuring.

Description

Features:

It is a kind of equipment for automatic weighing and packing of liquid materials in chemical, food, pesticide and other industries. The high precision electronic weight detection method is adopted for weighing and measuring. In order to control the automatic quantitative filling and filling operation of barrel raw materials with a high degree of automation, can avoid material overflow as far as possible, to prevent the material itself from polluting the environment to the greatest extent, so as to effectively protect the operator labor, at the same time the system can be used in wet, dangerous or other adverse environment.



Application scope of glue filling machine:

These filling machines are used to accurately and weight bulk liquid materials into various containers, iron drums or plastic drums. It’s 301 to 1000 liters Barrel automatic quantitative filling, widely used in chemical industry, food, pesticides and other liquid material related industries, suitable for paint, paint, ink, adhesive, curing agent, resin, dye, cleaning agent, oil, glycerin, lubricating oil, edible oil, flavor, solvent, additives, food additives, pesticides and other dangerous chemical products.



Functional characteristics of glue filling machine:

Product Settings: Store weight Settings and related filling parameters for up to 10 different products

Tolerance check: Check the full bucket tolerance, can effectively prevent material spillover

Multi-stage filling: can be divided into two (fast/slow) or three (slow/fast/slow) filling, greatly improve the filling accuracy

Throttling device: Effectively prevents spatter phenomenon caused by high initial pumping pressure when filling low viscosity products

Drip protection: High viscosity injection valve solves the drip phenomenon in the filling of high viscosity products, while low viscosity injection valve has automatic drip cup and air collecting hood device

Solid structure: the part in direct contact with the material is 316 stainless steel, 304 stainless steel, carbon steel, etc

Interlocking security: various processes are interlocked to ensure safe operation

Easy to operate: The filling system is easy to learn and operate



Flexible design: Various forms of equipment and optional parts are provided according to the raw material characteristics and container size on site, and the structure is compact

PARAMETER:

Model

MIC V01

Voltage

220V/380V 50/60HZ

Power

30W

Air Pressure

0.4-0.6MPa

Filling Speed

5-25 bottles/min

Filling Accuracy

±1%

Dimension(L*W*H)

1000*480*700mm

Filling Range

10-20ML. 25-250ML. 50-500ML.100-1000ML.250-2500ML. 1000-5000ML

Weight

35 Kg

Filling Material

Juice, Oil, Water, Sauce, Toothpaste, Cosmetic Cream, Hand Cream, Honey and etc

Note: If you need special customization. please feel free contact me.
