Automatic Paint Filling Machine(Speed 20-30 Tubes Per Minute)

A paint filling machine is a specialized piece of equipment designed to automate the process of filling paint or coating products into containers. It features a conveyor system that transports containers to the filling station, where a precise amount of paint is dispensed using a filling mechanism such as a positive displacement pump or flow metering system.

Description

Features:

A paint filling machine is a specialized piece of equipment designed to automate the process of filling paint or coating products into containers. It features a conveyor system that transports containers to the filling station, where a precise amount of paint is dispensed using a filling mechanism such as a positive displacement pump or flow metering system. The machine ensures accurate and consistent filling, minimizing waste and maintaining uniform fill levels across containers. With user-friendly controls, integration capabilities, and safety features, paint filling machines streamline production, improve efficiency, and enhance the overall quality of the filling process in the paint and coatings industry.

An automatic paint filling machine is a specialized equipment used for efficiently and accurately filling paint or coating products into containers. It is designed to automate the paint filling process, ensuring precision, consistency, and high production rates.



Here are some key features and functions of an automatic paint filling machine:

Container Handling: The machine is equipped with a conveyor system or indexing mechanism to transport containers to the filling station. It can handle various container types, such as cans, bottles, pails, or drums of different sizes and shapes.

Filling Mechanism: The filling mechanism of an automatic paint filling machine utilizes a positive displacement pump or flow metering system. This mechanism ensures precise measurement and control of the paint volume being dispensed into each container. It allows for accurate filling, minimizing product wastage and ensuring consistent fill levels.

Nozzle and Drip-Free Filling: The machine is equipped with a specialized filling nozzle designed to minimize drips or spills during the filling process. This helps maintain a clean and efficient production environment and prevents paint waste or contamination.

Automatic Control and Adjustment: Automatic paint filling machines typically have programmable controls and user-friendly interfaces. Operators can set desired fill volumes, speeds, and other parameters. The machine can automatically adjust filling parameters based on container size, ensuring accurate and efficient filling without manual intervention.

Integration and Connectivity: These machines can be integrated into existing production lines, allowing for seamless automation and synchronization with other processes such as paint mixing, labeling, capping, and packaging. They can also be connected to a central control system for data monitoring, production tracking, and quality control purposes.

Cleaning and Maintenance: Automatic paint filling machines often have features to facilitate easy cleaning and maintenance. They may include quick-change components, self-cleaning mechanisms, or CIP (clean-in-place) systems to minimize downtime and ensure hygienic operation.

Safety Features: Paint filling machines prioritize operator safety by incorporating safety mechanisms such as emergency stop buttons, interlocks, and guarding systems. These features help prevent accidents and ensure a secure working environment.

By utilizing an automatic paint filling machine, paint manufacturers can significantly increase production efficiency, improve accuracy and consistency in filling operations, reduce product waste, and enhance overall productivity.

PARAMETER:

CONFIGURATION:

Weight

250Kg

Dimension

1230*700*1400mm

Power

220V/50Hz

Motor

1.1Kw

Filling Quantity

3-30ml/5-75ml/30-200ml

Capacity

20-30 Tubes/min

Air Consumption

<30 m³/min

Heating Power

400W

Compressed Air

0.6-0.8Mpa

Quantity Error

<2%

PartsBrand

Main Motor

Wu XI Qi Peng

PLC

Panasonic JAPAN

Stepping Motor

East Japan

Stepping Drive

East Japan

Sensor

Germany Sick

Approach Switch

BFNFC

Intermediate Relay

Schneider

electromagnetic Valve

Si Mai Ge

Encoder

Omron

Mixing Motor (Optional)

XiangGang Ease

Air Cylinder

Si Mai Ge

Bearing

Nsk

Button

Schneider

Air Switch

CHNT

Power Switch

Omron

Temperature Control

HuoYU

APPLY:
