Gel Filling Machine(Skincare,Cream,Speed 30-40 Bottles Per Minute)

A gel filling machine is a type of equipment used to fill gel-like substances, such as creams, gels, or lotions, into containers or packaging. It is designed to accurately dispense a specific volume of gel product into each container, ensuring consistent and efficient filling.

Description

FEATURES:

A gel filling machine is a type of equipment used to fill gel-like substances, such as creams, gels, or lotions, into containers or packaging.  It is designed to accurately dispense a specific volume of gel product into each container, ensuring consistent and efficient filling.  The machine typically consists of a container or tube holder, a nozzle or dispensing mechanism, and controls for adjusting the filling volume and speed.



The features and advantages of a gel filling machine typically include:

Accurate and precise filling: Gel filling machines are designed to ensure precise and consistent filling volumes, minimizing product waste and ensuring uniformity across all containers.

High production efficiency: These machines are capable of filling a large number of containers quickly, improving production efficiency and reducing labor costs.

Versatility: Gel filling machines can handle a wide range of gel-like products, accommodating different viscosities and container sizes.

Easy operation and adjustment: Most gel filling machines are user-friendly, with intuitive controls for adjusting filling volumes, speeds, and other parameters.  They can be easily set up and operated by operators.

Hygienic and clean filling: These machines are designed with features that promote hygiene and prevent product contamination, such as stainless steel construction, easy cleaning, and optional sterilization mechanisms.

Reduced product loss: The precise filling mechanism of gel filling machines helps minimize product spills or leaks, reducing product loss and ensuring better cost-effectiveness.

Improved product presentation: The consistent filling achieved by these machines results in a professional and aesthetically pleasing appearance of the gel product in its packaging.

Integration capabilities: Gel filling machines can often be integrated into automated production lines, allowing for seamless integration with other packaging equipment and increasing overall production efficiency.

Reliable and durable: These machines are built to withstand continuous operation, ensuring reliability and longevity with proper maintenance.

It’s important to note that the specific features and advantages may vary depending on the manufacturer and model of the gel filling machine.

PARAMETER:

CONFIGURATION:

Suitable Filling Volume20-100ml
Production Speed30-40 Bottles/min
Filling Accuracy≤±1%
Voltage220V/50Hz Single Phase
Spain Rolling Cover Rate≥99%
Automatic Loading Brush Rate≥99%
Air Source2 m³/h 0.4-0.8Mpa
Power2kw
Machine Weight500kg
Size1530*2990*1500mm
PartsBrand
PLC Programmable Logic ControllerDelta Taiwan
PLC ModuleDelta Taiwan
Touch ScreenTaiwan Taian
Main MotorTaiwan Leeming
Conveyance MotorXiamen Lapping
AC ContactorSchneider
Intermediate RelaySchneider
Power IndicatorSchneider
Photoelectric SensorsSick
The Electromagnetic ValveExplosion-proof Solenoid Valves
Switching Power SupplyMing Wei
InverterDelta Taiwan
Pneumatic ComponentsAirTAC
BarometerAirTAC
Regulator FilterAirTAC

APPLY:
