Description
FEATURES:
An eye drop filling machine is a specialized piece of equipment used to automate the process of filling eye drop bottles with liquid medication. The machine is designed to handle the specific requirements of filling eye drop bottles, such as precise dosage control, accurate filling volumes, and aseptic filling to maintain product quality and safety.
Advantages and features of an eye drop filling machine include:
1.Increased Efficiency: The machine can fill a large number of eye drop bottles quickly and accurately, reducing the need for manual labor and increasing production efficiency.
2.Precision Filling: The machine is designed to ensure that each bottle is filled with the exact amount of medication, ensuring that patients receive the correct dosage every time.
3.Aseptic Filling: Eye drop filling machines are designed to maintain the sterility of the medication, preventing contamination and ensuring patient safety.
4.Flexibility: Eye drop filling machines can handle a wide range of bottle sizes and can be customized to accommodate different types of liquid medication.
5.Cost-Effective: Automating the filling process with an eye drop filling machine can save on labor costs and reduce waste, resulting in a cost-effective solution for pharmaceutical manufacturers.
Overall, an eye drop filling machine is an essential tool for pharmaceutical companies looking to improve their production efficiency, accuracy, and safety in the manufacturing process of eye drop medication.
PARAMETER:
CONFIGURATION:
Type | Bottle conveyoring → bottle feeding → bottle filling → loading inner stopper → loading outer Cap → outer Cap capping → bottle outlet by rotary table
|
Filling Volume | 5-10ml (can be customized)
|
Filling Speed | ≥130bpm
|
Filling Error | ≤±1%
|
Pass Rate | ≥99.9%
|
Filling Type | Ceramic pump or peristaltic pump
|
Filling Temperature | Room
|
Air pressure | 0.4-0.6MPa;consumption 10-25L/min
|
Power | 2.5kw
|
Voltage | 380V/50/60hZ (can be customized)
|
Weight | About 1500kg
|
No. | Name | Type | Brand |
1 | Filling pump | Ceramic pump or peristaltic pump | China |
2 | Filling heads | Customized | China |
3 | Stopper heads | Customized | China |
4 | Capping heads | Customized | China |
5 | PLC | TM218LDA40DR2HN | Schneider |
6 | Touch screen | 3500 | Schneider |
7 | Frequency converter | ATV310H075N4A | Schneider |
8 | Main electrical components | / | Schneider |
9 | Main pneumatic components | / | Schneider |
10 | Main motor | 0.75KW | China |
11 | Reducer | WPDS70-20 | China |
12 | Conveyor motor | 200W 1:25 | China |
13 | 80 dividing box | 1:18 | China |
14 | Material of equipment keel | A3carbon steel | China |
15 | Main material | Cover is SUS304, liquid contacting parts SUS316L | China |
